IEC 60320 C15 high temperature female Connector

C15 high temperature coupler is widely used for electric kettles, water boilers, servers, network racks, industrial power supplies and other equipment with high working temperature. It can be supplied as separate connectors or finished molded power cords matched with various country plugs: Schuko, NEMA 5-15P, UK BS, Australian plug etc.

Our factory supports OEM & ODM service, including custom length, wire gauge, logo printing and packaging. Strict electrical testing ensures stable performance for wholesale and project orders.

Bullet Points

✅ IEC 60320 C15 high temperature female coupler, 120℃ heat resistant

✅ Special notch design to prevent mis-insertion

✅ Rated 10A 250V AC, 3-pin grounded connection

✅ Nickel-plated brass contacts, stable power transmission

✅ For kettle, server, boiler and high temp equipment

✅ Standalone connector or finished power cord available

✅ UL/VDE/CE/RoHS certification & OEM supported

Plug Type	3 Wire Connector
Approvels	ETL, KC, PSE.CE, SAA, VDE
Voltage	125V, 250V
Plug / Connector Standards	IEC 60320
Model No.	C15

Category: IEC 60320 Power Connectors

high temperature C15 connector Descriptions

Model No.	C15
Type	3 Wire Connector
Rated Current	10A,13A,15A
Rated Voltage	250V,125V
Standard（s)	IEC 60320
Approvals	ETL,VDE,SAA,PSE.CE，KC
Jacket Material	PVC
Plug Insert Material	PBT/ABS
Plug Pin Material	Copper/Nickel Plasting
Color	Black/White/Customized
Country of Origin	Made In China

IEC C15 power connector Wire Styles

Gauge/ # Conductors	Cord Type
3×0.5mm²	H03VV-F, RVV, YZ, YZW
3×0.75mm²	H03VV-F, H05VV-F, H05RR-F, H05RN-F, H03RT-F, RVV, YZ, YZW
3×1.0mm²	H05VV-F, H05RR-F, H05RN-F, H03RT-F, H07RN-F, RVV, YZ, YZW
3×1.5mm²	H05VV-F, H05RR-F, H05RN-F, H03RT-F, H07RN-F, RVV, YZ, YZW
18/3	SVT, SVTO, SVTOO, HPN, SPT-2, SPT-3, SJT, SJTW, SJTO, SJTOW, SJTOO, SJTOOW
16/3	SJT, SJTW, SJTO, SJTOW, SJTOO, SJTOOW, SPT-2, SPT-3, HPN
14/3	SJT, SJTW, SJTO, SJTOW, SJTOO, SJTOOW, SPT-3

IEC 60320 C15 is a high-temperature female appliance coupler. It features a special notch and heat-resistant housing up to 120°C. Designed for high heat applications such as electric kettles, servers and industrial equipment. Available as molded cord assembly or standalone connector with multiple certifications & OEM service.
